Navigating the Processes page

View a list of all processes on the Processes page. To view the processes for an individual panel, see Processes tab. Each row represents a single process and each row displays the following information:

• Process start time and duration

• Process creator name

• Panel ID

• Process description

• Current status

• Duration

This information is contained in the column titles: TIMING, USER, PANEL, PROCESS, and STATUS.

Filter your search of the Processes page by selecting one or more filter values from the Search list. From the Search list, select a filter value from one or more of the following keys: PANEL ID, PANEL NAME, TYPE, USER, STATUS, STARTED AT. For more information, see Using the search filter .

Figure 49. Navigating the Processes page

PM_4.16_EN_Navigating_the_Processes_page

Callout	Name	Description
1	Check box	Select the check box of one or more processes to enable use of STOP.
2	TIMING	Displays the start time, and the total or current runtime of the process. For more information, see Process duration column .
3	USER	Displays the initials of the user that initiates the process Note: If a process requires a subsequent task to complete the current process, the username for the subsequent process task is SYSTEM.
4	User information	Hovering over the user initials, displays the user’s information.
5	PROCESS	A description of the process
6	STATUS	A description of the of the process status. A progress bar indicates the process is running and the warning icon indicates that the process stopped. The text after the warning icon indicates the reason the process stopped.
7	Cancel process	Click to stop a process that runs You can only stop one process at a time.
