Navigating the Basic configurations page

Manage the panel configurations that you create on the Basic Configurations page. A basic configuration is a copy of one or more configuration parameters from an existing panel that you can use for multiple panels. To create a basic configuration from an existing panel configuration, see Creating a basic configuration from an existing panel configuration .

To push a basic configuration to one or more panels, see Pushing a basic configuration to one or more panels .

Each row on the page represents a basic configuration. A row displays the configuration name, panel model, creation date, and update time. This information is contained in the column titles: NAME, PANEL MODEL, CREATED, and UPDATED.

Filter your search of the Basic Configurations page by selecting one or more filter values from the Search list. From the Search list, select a filter value from one or more of the following keys: NAME, VENDOR, and CREATED. For more information, see Using the search filter .

Figure 55. Navigating the basic configurations page

Callout	Name	Description
1	Check box	Select the check box of one or more basic configurations to enable REMOVE.
2	REMOVE	Click to remove one or more basic configurations
3	Basic con- figuration	Click the basic configuration row to view a list of the panels eligible for configuration.
4	Edit con- figuration	Click to edit the basic configuration. For more information about basic configuration parameters, see Basic configuration parameters .
