Callout

Name

Description

1

TODAY

Click to return to today's date.

2

Year and month filter

Use the arrows to navigate the remote inspections by year or month on the calendar interface. When you are in the monthly view, click the button between the arrows to return to the annual view.

3

Month

Select the month to open it in the viewer. The current month is highlighted.

4

Inspection

All scheduled remote inspections appear in the calendar. The colors of the report indicates the following test statuses:

• Red: the test failed

• Green: the test succeeded

5

Send email

Click the email icon to send the results of the remote inspection to a predefined email address.

Note:

• Define the email address when you add a panel on the Panels page. For more information, see Adding a panel to the server.

• Change the email address on the INFO tab. For more information, see Editing basic panel and customer information.

6

Viewing status

Click to mark the remote inspection as viewed.

The remote inspection is viewed. Only mark a remote inspection as viewed if your investigation is complete.

7

START INSPECTION

Click to initiate the selected remote inspection.

8

SCHEDULE INSPECTION

Click to schedule the selected remote inspection to occur at a specific date and rate of recurrence. For more information, see Scheduling a remote inspection for an individual panel.

9

Examination pane

To examine the results of a remote inspection in the examination pane, click the remote inspections row. The results are ordered in three categories: FAILED TESTS, NOT COMPLETED TESTS and PASSED TESTS. From this pane you can sign the test as REVIEWED, SEND EMAIL and rerun the test. Select a section title to expand the test results. For more information on each test, see Remote

inspection tests.
